FX (36 x 24) image area: 7,360 x 4,912 (L), 5,520 x
3,680 (M), 3,680 x 2,456 (S) 1.2x (30 x 20) image
area: 6,144 x 4,080 (L), 4,608 x 3,056 (M), 3,072 x
2,040 (S) DX (24 x 16) image area: 4,800 x 3,200
(L), 3,600 x 2,400 (M), 2,400 x 1,600 (S) 5 : 4 (30
x 24) image area: 6,144 x 4,912 (L), 4,608 x 3,680
(M), 3,072 x 2,456 (S) FX-format photographs taken
in movie live view: 6,720 x 3,776 (L), 5,040 x 2,832
(M), 3,360 x 1,888 (S) DX-format photographs in
movie live view: 4,800 x 2,704 (L), 3,600 x 2,024
(M), 2,400 x 1,352 (S) Note: Photographs taken in
movie live view have an aspect ratio of 16 : 9. A
DX-based format is used for photographs taken using
the DX (24 x 16) 1.5x image area; an FX-based format
is used for all other photographs.
ความไวแสง
ISO 100 - 6400 in steps of 1/3, 1/2, or 1 EV. Can
also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO
50 equivalent) below ISO 100 or to approx. 0.3, 0.5,
0.7, 1, or 2 EV (ISO 25600 equivalent) above ISO
6400; auto ISO sensitivity control available
ฟอร์แมทไฟล์
NEF (RAW): 12 or 14 bit, lossless compressed,
compressed, or uncompressed TIFF (RGB) JPEG:
JPEG-Baseline compliant with fine (approx. 1 : 4),
normal (approx. 1 : 8), or basic (approx. 1 : 16)
compression (Size priority); Optimal quality
compression available NEF (RAW)+JPEG: Single
photograph recorded in both NEF (RAW) and JPEG
formats
เมมโมรี่การ์ด
SD (Secure Digital) and UHS-I compliant SDHC and
SDXC memory cards; Type I CompactFlash memory cards
(UDMA compliant)
White Balance
Auto (2 types), incandescent, fluorescent (7 types),
direct sunlight, flash, cloudy, shade, preset manual
(up to 4 values can be stored), choose color
temperature (2500 K-10000 K), all with fine-tuning.
หน้าจอ LCD
8-cm/3.2-in., approx. 921k-dot (VGA) TFT LCD with
170 ° viewing angle, approx. 100% frame coverage,
and automatic monitor brightness control using
ambient brightness sensor
ฟังก์ชั่นการแสดงภาพ
Full-frame and thumbnail (4, 9, or 72 images)
playback with playback zoom, movie playback, photo
and/or movie slide shows, highlights, histogram
display, auto image rotation, and image comment (up
to 36 characters)
Type B BriteView Clear Matte Mark VIII screen with
AF area brackets and framing grid
ออโต้โฟกัส
Nikon Advanced Multi-CAM 3500FX autofocus sensor
module with TTL phase detection, fine-tuning, 51
focus points (including 15 cross-type sensors), and
AF-assist illuminator (range approx. 0.5-3 m/1 ft 8
in.-9 ft 10 in.)
โหมดโฟกัส
Autofocus (AF): Single-servo AF (AF-S);
continuous-servo AF (AF-C); predictive focus
tracking automatically activated according to
subject status Manual focus (M): Electronic
rangefinder can be used
ระบบวัดแสง
Matrix: 3D color matrix metering III (type G and D
lenses); color matrix metering III (other CPU
lenses); color matrix metering available with
non-CPU lenses if user provides lens data
Center-weighted: Weight of 75% given to 12 mm circle
in center of frame. Diameter of circle can be
changed to 8, 15, or 20 mm, or weighting can be
based on average of entire frame (non-CPU lenses use
12-mm circle or average of entire frame) Spot:
Meters 4 mm circle (about 1.5% of frame) centered on
selected focus point (on center focus point when
non-CPU lens is used)
ช่วงการวัดแสง
Matrix or center-weighted metering: 0-20 EV Spot
metering: 2-20 EV
ระบบบันทึกภาพ
Programmed auto with flexible program (P);
shutter-priority auto (S); aperture-priority auto
(A); manual (M)
Front curtain sync, slow sync, rear-curtain sync,
red-eye reduction, red-eye reduction with slow sync,
slow rear-curtain sync; Auto FP High-Speed Sync
supported
ช่องเสียบสายซิงค์
ISO 519 sync terminal with locking thread
ถ่ายภาพแบบหน่วงเวลา
2 s, 5 s, 10 s, 20 s; 1-9 exposures at intervals of
0.5, 1, 2, or 3 s
GPS
Via 10-pin Remote Cord. Can be used to connect
optional remote control, GP-1 GPS unit, or GPS
device compliant with NMEA0183 version 2.01 or 3.01
(requires optional MC-35 GPS adapter cord and cable
with D-sub 9-pin connector)
Rechargeable Li-ion EN-EL15 battery, EH-5b AC
adapter, requires EP-5B power connector (optional)
ช่องเสียบขาตั้งกล้อง
1/4 in. (ISO 1222)
ขนาด
Approx. 146 x 123 x 81.5 mm (5.7 x 4.8 x 3.2 in.)
น้ำหนัก (ไม่รวมแบตเตอรี่,เมมโมรี่การ์ด
Approx. 1,000 g (2 lb 3.3 oz) with battery and SD
memory card but without body cap; approx. 900 g/1 lb
15.7 oz (camera body only)
อุปกรณ์มาตรฐาน (ต่างกันในแต่ประเทศ)
EN-EL15 rechargeable Li-ion battery with terminal
cover, MH-25 battery charger (AC wall adapter
supplied only in countries or regions where
required), Strap (AN-DC6 for D800, AN-DC6E for
D800E), UC-E14 USB cable, USB cable clip, BF-1B body
cap, BS-1 accessory shoe cover, BM-12 monitor cover,
ViewNX 2 installer CD
